CNC Wood Router
The 1530 CNC Wood Router is a high-precision computer-controlled cutting and carving machine, designed for woodworking industries that require speed, accuracy, and durability. With a strong steel structure, advanced spindle technology, and versatile operating capabilities, it is widely used for furniture making, decorative panel cutting, sign-making, and intricate 3D wood carving.
Company Address
38/4, Delhi – Rohtak Rd, Below Tikri Kalan Metro Station-Gate No-2, Tikri Kalan, Delhi 110041
Phone: (+91) 97116 10835
Email: info@angelindiaimpex.com
Product Features:
1. Heavy-Duty Steel Frame:
○ Built from an entire welded steel structure.
○ High-temperature stress relief treatment ensures stability and long-lasting durability.
○ Eliminates frame deformation during heavy operations.
2. Smooth & Accurate Motion System:
○ Gantry movement style design for stable and balanced performance.
○ Y-axis equipped with double-driven motors for faster movement and higher precision.
3. High-Performance Spindle:
○ Available with multiple spindle options ranging from 3kW to 9kW.
○ Water-cooled design ensures efficient, long-time continuous operation.
4. Versatile Table Design:
○ T-slot table for secure material clamping.
○ Optional vacuum adsorption system for high efficiency.
5. Easy-to-Use Control System:
○ Compatible with advanced controllers like NK 105 or RichAuto DSP controllers.
○ Supports multiple file formats and G-codes.
6. Applications Across Materials:
○ Capable of working with wood, acrylic, MDF, PVC, aluminum, and soft metals.
○ Ideal for both 2D cutting and 3D engraving.
Technical Parameters:
- Model: 1530 CNC Wood Router
- Working Area: 1500mm × 3000mm × 200mm
- Running Speed: Up to 50m/min (depends on material thickness)
- Spindle Motor Power Options: 3kW / 4.5kW / 6kW / 7.5kW / 9kW
- Spindle Speed: 0–18,000 RPM, 0–24,000 RPM, 0–36,000 RPM
- Operating System: NK 105 or RichAuto Controller
- Drive System: Rack and Pinion drive with stepper motor
- Z-Axis Feed: 120mm (customizable)
- Holding Method: T-slot or Vacuum table (optional)
- Optional Devices: Dust collector (single or double bag), mist cooling system, vacuum pump
- Command Code Supported: G-code, HPGL, Uoo, etc.
- Applicable Materials: Wood, Acrylic, MDF, Hard Wood, PVC, Aluminum Sheet, Plastic
- Oil Supply System: Automatic lubrication system
Applications:
The 1530 CNC Wood Router is extensively used in industries like:
○ Furniture Manufacturing: Carving, cutting, and shaping wooden furniture components.
○ Interior & Exterior Decoration: Designing wall panels, doors, partitions, and ceilings.
○ Advertising Industry: Cutting and engraving signboards, logos, and decorative panels.
○ Crafts & Artwork: Intricate 2D and 3D wood carving, artistic engravings, and mold making.
○ Soft Metal Processing: Cutting and engraving aluminum, copper, and composite materials.
In Summary:
The 1530 CNC Wood Router is a versatile, heavy-duty, and user-friendly CNC machine that delivers high precision, strong cutting power, and smooth operation. Its customizable spindle options, advanced control systems, and durable structure make it an excellent investment for businesses in woodworking, advertising, and interior design industries.
